Start your first test execution

Test Observer is a dashboard for viewing and managing test results on software artefacts across different environments. You can integrate Test Observer with your testing pipelines to monitor test results over time.

In this tutorial, you will learn how to report test results to Test Observer using its REST API. You will create a Python script that starts a test execution, submits test results, and marks the execution as complete.

Understand the workflow

Test Observer does not run tests itself, instead, it is a tracking and reporting system that stores test results from external test runners.

The integrated workflow consists of three main steps:

        sequenceDiagram
   participant Runner as Your test runner
   participant TO as Test Observer

   Runner->>TO: Start a test execution
   TO-->>Runner: Return <test_execution_id>
   Runner-->>Runner: Execute tests and collect results
   Runner->>TO: Submit test results
   Runner->>TO: Complete the test execution
   TO-->>TO: Calculate overall status

  1. Start a test execution: your test runner calls Test Observer API to specify what artefact or software package is being tested.

    An artefact is a Debian package, snap, charm, or system image with a specific name and version. A test execution groups all test results from one test session together for a specific artefact version in a particular environment.

  2. Submit test results: the test runner submits individual test results to the registered test execution ID.

  3. Complete the test execution: the test runner signals that testing is finished so Test Observer can calculate the overall execution status based on all submitted test results.

Set up your workspace

Before starting, ensure you have the following prerequisites:

  • Access to Test Observer instance (the Canonical production and staging instances require VPN access)

  • An API key with change_test permission to the instance (contact Test Observer administrators)

Note

We will use the Canonical staging instance in this tutorial as an example. The staging API server is available at: https://test-observer-api-staging.canonical.com/. If you need to use other instances, replace the base URL accordingly.

Create a project directory and install the requests library to communicate with the Test Observer API:

python3 -m venv venv
source venv/bin/activate
pip install requests

Configure authentication

Test Observer requires an API key to accept test results from automation tools. In this tutorial, we will create Python script that uses an environment variable to securely store the API key.

For example, store your API key in an environment variable as follows:

$ export TO_API_KEY="your-api-key"

Create a file named submit_test.py and add the following code to set up authentication:

#!/usr/bin/env python3
import os
import requests
import sys

# Basic configuration
BASE_URL = "https://test-observer-api-staging.canonical.com"
API_KEY = os.getenv("TO_API_KEY")

headers = {
    "Authorization": f"Bearer {API_KEY}",
    "Content-Type": "application/json"
}

The headers dictionary will be used in all subsequent API requests to authenticate with Test Observer.

Start a test execution

Before submitting test results from the runners, you must start a test execution to tell Test Observer what you are testing and where the tests are running.

The test execution is defined by the artefact details and environment. The following example simulates the workflow by creating fake test results for a Debian package named hello-world-app in a test environment called tutorial-laptop:

# Define what we are testing
payload = {
    "family": "deb",
    "name": "hello-world-app",
    "version": "1.0.0-ubuntu1",
    "arch": "amd64",
    "environment": "tutorial-laptop",
    "test_plan": "smoke-tests",
    "series": "noble",
    "repo": "main",
    "execution_stage": "proposed",
}

Note

You can find the required fields for different artefact families in the Staging API or Production API specification.

Send a PUT request to the /v1/test-executions/start-test endpoint with this payload to register the test execution. Add the following code to your submit_test.py file:

print(f"Base URL: {BASE_URL}")
print(f"Starting test execution for {payload['name']} {payload['version']}...")

# Send PUT request to start the execution
try:
    response = requests.put(
        f"{BASE_URL}/v1/test-executions/start-test",
        json=payload,
        headers=headers,
        timeout=30
    )
    response.raise_for_status()
except requests.exceptions.RequestException as e:
    print(f"Failed to start execution: {e}")
    sys.exit(1)

execution_id = response.json()['id']
print(f"Execution ID: {execution_id}")

Run the updated script:

$ python3 submit_test.py

Base URL: https://test-observer-api-staging.canonical.com
Starting test execution for hello-world-app 1.0.0-ubuntu1...
Execution ID: 42

The returned execution_id is a unique identifier for this test run. You will use this ID to submit results and complete the execution.

Submit test results

Now that the execution is registered, you can submit test results as a grouped record. Each individual test result includes the test name, status, comments, and optional logs.

The following code example simulates submitting four test results: two passes, one failure, and one skipped test. Note that the test names should be unique within your test framework.

# Define test results
test_results = [
    {
        "name": "test_boot",
        "status": "PASSED",
        "comment": "System booted in 15 seconds",
        "category": "boot",
    },
    {
        "name": "test_audio",
        "status": "PASSED",
        "comment": "Audio playback working correctly",
        "category": "audio",
    },
    {
        "name": "test_wifi",
        "status": "FAILED",
        "comment": "Could not connect to network",
        "category": "wifi",
        "io_log": "Error: Unable to connect to network ...",
    },
    {
        "name": "test_performance_benchmark",
        "status": "SKIPPED",
        "comment": "Requires GPU, not available in this environment",
        "category": "performance",
    },
]

print(f"Submitting {len(test_results)} test results...")

To submit the list of test results, send a POST request to the /v1/test-executions/ endpoint. Add the following code to your submit_test.py file:

try:
    response = requests.post(
        f"{BASE_URL}/v1/test-executions/{execution_id}/test-results",
        json=test_results,
        headers=headers,
        timeout=30
    )
    response.raise_for_status()
except requests.exceptions.RequestException as e:
    print(f"Failed to submit results: {e}")
    sys.exit(1)

print("Results submitted")

Run the updated script again:

$ python3 submit_test.py
...
Submitting 4 test results...
Results submitted

Note

You can call the test-results endpoint multiple times to submit results in batches. Test Observer appends each batch to the execution.

Complete the execution

After all test results are submitted, you must mark the execution as complete. This triggers Test Observer to parse the submitted results and calculate the overall execution status:

  • PASSED (if all tests passed)

  • FAILED (if any required tests failed)

  • ENDED_PREMATURELY (if no tests were submitted)

Call the PATCH endpoint to mark the execution as complete:

print("Marking execution as complete...")

try:
    response = requests.patch(
        f"{BASE_URL}/v1/test-executions/{execution_id}",
        json={"status": "COMPLETED"},
        headers=headers,
        timeout=30
    )
    response.raise_for_status()
except requests.exceptions.RequestException as e:
    print(f"Failed to complete execution: {e}")
    sys.exit(1)

print(f"Success! Your test execution is complete (ID: {execution_id})")

Run the complete script:

$ python3 submit_test.py
...
Marking execution as complete...
Success! Your test execution is complete (ID: 42)

Verify in the dashboard

You can view your test execution results through the web interface. To find your execution, navigate to https://test-observer-staging.canonical.com/artefacts?family=deb and use the search box and filters to find the artefact name: hello-world-app and version 1.0.0-ubuntu1

The execution status should show FAILED because one test failed in our submitted results. Expand and check the individual test results and their logs.

Congratulations! You have successfully submitted your first test results to Test Observer using the REST API. You can now integrate Test Observer into your CI/CD pipelines to track test results across your projects.
